Surveillance Ball
The Surveillance ball is a system specially designed for wireless real-time intelligence. The sensor is round in shape like a ball. It is rugged enough to survive a hit or knock and can be thrown to distant area where might be dangerous. Then it transmits real-time video and audio to monitor simultaneously. Operator is able to observe what is going on in hidden place without being at dangerous place. Thus, when you have to take measures in a building, basement, cave, tunnel or lane, risk is reduced. This system is applicable to policeman, military policeman and special operation force to take anti-terrorism action or maintain surveillance in city, countryside or outdoors.
This device is fitted with some NIR-LED, so the operator can search and monitor objects in dark environment.
| Scanning Mode | 360° Rotating Automatically;Rotating Speed ≧4circles/m |
| 360° Rotating by Manual | |
| Camera | ≧1/3’’, Color video |
| Angle of Field | ≧52° |
| Audio/Microphone Sensitivity | ≦-3dB, ≧8meters |
| Signal to Noise Ratio | ≧60dB |
| Light Source | NIR-LEDS |
| Light Source Distance | ≧7m |
| Audio/Video Output | Wireless |
| Data Transmission | Wireless |
| Diameter of Ball | 85-90mm |
| Weight of Ball | 580-650gram |
| Display Resolution | ≧1024*768, Colorful |
| Display | ≧10 inches TFT LCD |
| Battery | ≧3550mAh, Lithium Battery |
| Continuous Working Time | ≧8hours |
| Weight of Display | ≦1.6kg (without antenna) |
| Remote Distance | 30m |
